Details
USA Comway Cc-01 Fiber cleaver
Features
* Comway Fiber Cleaver
* High Capacity Cleaver Cleave upto 80,000 cuts
* Manual Cleaver with all fiber camparative
* Dustbean available
* Easy to Change blade position
Cutting angle: 0.5 °
Fiber diameter: 125μ m.
Coating Diameter: 0.25mm and 0.9 mm
Dimensions: 63 W × 76D × 63 H (mm).
Weight: 430 grams
Blade Life: 36,000 core (1000core×12 blade angle × 3 blade height)
Specification
| Model Type | CC-01 |
| Fiber Type | Silicon(Single mode or Multimode) |
| Coating Diameter | 250μm-900μm |
| Bare Fiber Diameter | 125μm |
| Cleaver Angle Capability | Typically <0.5° |
| Cleave Length | 9-24mm |
| Blade Diameter | 20mm |
| High Precision Blade | 24 Cleave positions (each position 2,000) |
| Blade Lifetime | 48,000 |
| weight | 450g |
| Dimension | D62*W58*H51(mm) |
