MTRJ fiber optic connector Kit
Product Description
LC-MTRJ Fiber Optic Connectors
Connector Type: Duplex LC Male, MTRJ Female
Cable type: Duplex Zipcord cable
Jacket Color: Orange
Insertion Loss≤ 0.2dB
Return Loss ≥ 50dB(UPC)
Exchangeability ≤ 0.2dB
Repeatability(500 matings) ≤ 0.1dB
Tensile Strength ≥ 5kg
Operating Temperature: -20~+70 C
Storage Temperature: -40~+70 C
Features
Low insertion loss, High return loss
User friendly, Compact size
PVC or LSZH Jacket
PC/UPC/APC Polish
Good exchangeability and repeatability
Comply with Telcordia GR-326-CORE Specification
Application:
Optical fiber communication systems
Fiber optic data transmission
Local Area Network (LAN)
Fiber optic CATV
| Item | LC, SC, ST, FC, MTRJ, MU, SMA, etc | ||
| Type | Multi-Mode | Single-Mode | |
| Light Characteristic | Operating Wavelength | 850nm& 1300nm | 1310nm & 1550nm |
| Typical Insertion Loss | 0.2dB & 0.2dB | 0.2dB & 0.2dB | |
| Mechanical Testing | Repeatability | ≤ 0.2dB | |
| Exchange | ≤ 0.2dB | ||
| Durability | > 1000 (Times) | ||
| Temperature | Storage Temperature | 25 ~+85 | |
| Operating Temperature | 25 ~+85 | ||
| Length, Color, Out-Diameter, Fiber counts | According to the customers' requirement | ||
