LC PC MM SX Fiber Patch Cord Fiber Optic Patch Cord, also named Fiber Optic Jumper or Fiber Optic Patch Cable, is one of the most frequently used components in fiber optic network, and is used to Features: 1.Price-Competitive 2.Low Insertion Loss & PDL 3. Customized lengths(1m/2m/3m) 4.Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber 5.Polishing Options: PC/UPC/APC 6.Feature Connector with Ceramic Ferrules Details: Parameters Standard Fiber Cable Assemblies Fiber Type SM(G.652/G.657A) MM(OM1/OM2/OM3) Jacket Materials LSZH/OFNR/PVC Connector Type SC/LC/ST/LC/MU/MTRJ/MPO/E2000 Ferrule Materials Ceramic Testing Wavelengths 1310±30/1550±30nm 850±30/1300±30nm Insertion Losss(dB) ≤ 0.3dB ≤ 0.3dB TIA/EIA-455-107 (PC/UPC/APC) (PC/UPC) Return Loss(dB) ≥45dB(PC/UPC) ≥35dB(PC/UPC) TIA/EIA-455-107 ≥55dB(APC) Exchangeability ≤ 0.2dB Cable Assemblies Pigtail/Simplex/Duplex/Fan-out Patchcord Operating Temperature (° C) -10~ + 70 Storage Temperature (° C) -40 ~ +85 Package 1unit/bag
link the equipments and components in fiber optic network.
