Details
E2000/APC Fiber Optic Patch Cord
Feature: 1.Low insertion loss and back reflection loss 2.Good echangeability 3.Good Durability 4.High temperature stability. 5.Standard: Telcordia GR-326-CORE 6.Precise connector 7.Excellent mechanical capability 8.Patch cords accord with bellcord GR-326 ,ISO9001,RoHS Mode SM MM Polish UPC APC PC Insertion Loss Typical ≤0.2dB Maximum ≤0.3dB ≤0.25dB Return Loss ≥50dB ≥65dB ≥35dB Interchangeability ≤0.2dB Repeatability ≤0.1dB Durability ≤0.2dB (1000 times mating) Tensile Strengh > 10kg Temperature ≤0.2dB (-40+85 sustain 100 hours) Humidity ≤0.2dB (+25+65 93 R.H.100 hours)
Specification:
