DWDM multiplexer Optical deMux filters
Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. FCST provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE-2001 and GR-1221-CORE-1999 requirements. Features: Low Insertion loss Low PDL Compact Design Good channel-to-channel uniformity Wide Operating Wavelength:From 1260nm to 1650nm Wide Operating Temperature: From -40°C to 85°C High Reliability and Stability Applications: FTTX Systems PON Networks CATV Links Optical Signal Distribution Compliance: Telcordia GR-1209-CORE-2001 Telcordia GR-1221-CORE-1999 RoHS 1×N,2XN box module PLC Splitter 3.8/ 4 4.0/ 4.2 7.1/ 7.3 7.6/ 7.8 10.2/ 10.5 11.0/ 11.2 13.5/ 13.7 14.4/ 14.61×2 2×2 1×4 2×4 1×8 2×8 1×16 2×16 1×32 2×32 1×64 2×64 1×128 Operating Wavelength(nm) 1260~1650 Insertion Loss (dB)(P/S Grade) 16.5/ 16.9 17.5/ 17.9 20.5/ 21.0 21.0/ 21.5 24.2/ 24.5 Loss Uniformity(dB) 0.4 0.6 0.6 1 0.8 1.2 1.2 1.5 1.5 2 2 2.2 2.5 Return Loss (dB)(P/S Grade) 55/50 Polarization Dependent Loss(dB) 0.2 0.2 0.2 0.2 0.2 0.3 0.25 0.3 0.3 0.4 0.35 0.4 0.5 Directivity (dB) 55 Wavelength Dependent Loss(dB) 0.3 0.3 0.3 0.4 0.3 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 Temperature Stability (-40~8°C)(dB) 0.4 0.4 0.4 0.4 0.4 0.4 0.5 0.5 0.5 0.5 0.5 0.5 0.5 Operating Temperature(°C) -40~85 Storage Temperature(°C) -40~85 Module Dimension (mm)(L×W×H) 100×80×10 140×115×18
