Cat6a Twisted Pair Gold Plated RJ45 Lan Cable
Cable Specification:
| Twisted pair: | 4P | Conductor Type: | Solid | ||||
| Conductor size : | 22AWG/23AWG/24AWG | Conductor Material: | OFC/BC/CU/CCAG/CCA/CCS | ||||
| Center Splitter: | YES | Shield: | Unshielded | ||||
| Jacket Layer: | Single | Print word on cable: | As Clients' Request | ||||
| Drain wire: | NO | Braid: | NO | ||||
| Length: | 305M /or as your request | Jacket Color: | Optional | ||||
| Electrical Characteristic: | |||||||
| Impedance: | 100±15Ω at 1~250MHz | Stretching Resistance: | (max)400N | ||||
| NVP: | 66% | Bending Radius: | (min)8 times the outer diameter | ||||
| Operating Temperature: | -40 °C - +70 °C | Retardation Deviation: | (max)45ns/100m | ||||
| Reference Standard: | |||||||
| YD/T1019-2001, ANSI/TIA/EIA-568B, ISO/IEC11801 | |||||||
| Certification: | |||||||
| CE,ROHS | |||||||
| Application: | |||||||
| Computer Network Cabling Project / Broadband Network Communication Ethernet Network / Audio and Data Transmission | |||||||
Packing Information:
1.305m/box,pull out box ,2boxes/ctn
2.Pull out box size:40cmx40cmx24cm
3.Outside carton size:52cmx41cmx41cm
4.Weight:7.5kgs~14kgs per box (depend on different specification)
5.OEM/ODM Packing is available
