Details
CI-03RT Ribbon Fiber Fiber Cleaver
Feature:
1.Typical cleave angle:90°± 0.5°
2.Compact & handy outfit design.
3.Adjustable cleave length:5~20mm.
4.Scratch-free anodized body surface.
5.Configuration:single(250~900mm),Ribbon(2~12).
6.High precision cleaving blade with 16 cleave spots.
Specifications:
ITEM | PERFORMANCE |
Fiber Diameter | 100~150um |
Coating Diameter | 250~900um |
Cleave Angle | 90°± 0.5° |
Cleave Length | Single fiber standard:5~20mm |
Blade Lifetime | 50000 cleaves |
Net Weight | 0.26Kg |
Dimension | 58mm*55mm*48mm |
