Waterproof Fullaxs-LCUPC SX DX 4.8mm 5M Fiber Patch Cord
FullAXS
is a sealing system for optical and electrical interfaces which mates
directly into the SFP modules through a bulkhead construction. The
3-step sealing system is designed to accommodate for a large tolerance
in Z-direction and therefore accepts different transceiver modules.
FullAXS is a brand and technology owned by TE.
Ruggedised sealing system for fiber-to-the-antenna and industrial applications
Open bulkhead for easy access to SFP
Positive mechanical feedback to operator when fully mated
Duplex LC interface
Robust bayonet locking for easy, fast, and secure mating
Waterproof (IP65), dust proof and corrosion resistant
Expansion to RJ45 and power possible
FTTA feeders for all common RRH models and systems
Ruggedised design and installation proof
Standard assemblies and customised lengths available with short lead-time
Cable diameter 4.8 mm, 5.5 mm or 7 mm
All cables rodent resistant
All cable assemblies factory-terminated and tested
UL (OFNR) and Anatel approved cables available on request
ITEM | PARAMETER |
Connector type | LC,SC,FC,ST,E2000 |
Insertion Loss | <0.3dB |
Return Loss | SM>50dB,APC>60dB,MM>35dB |
Repeatability | <=0.1 |
Interchangeability | <=0.2dB |
Durability | <=0.2dB |
Fiber Length | 1m, 2m….. any length optional. |
Length and tolerance | 10cm |
Operating Temperature | -20C ~ +85C |
Storage Temperature | -20C ~ +85C |
