Full-Color Touch Screen Programmable Fiber Polishing Machine UTOUCH-21S
Features:
01.The UTOUCH-21S machine can polish a certain amount ferrule or connector in a short time (Different polishing fixture is different in polishing ferrule or connector)
02. Simple operation and maintenance
03. Be suitable in LC/UPC, LC/APC, FC/UPC, FC/APC, SC/UPC, SC/APC, ST/UPC, MTRJ, MT/PC, MT/APC and E2000 and other types of connector
04. Speed regulation control, speed selection scope is 30 ~ 160 RPM. Slow start function.
05. The polishing time can be reduced to the original by 1/2
06. Load ability: Allow more of 48 PCS fiber optic connectors
07. The password keeps all polishing parameter not to modify, make sure you have the correct polishing process will not be changed.
08. The Full-Color Touch Screen Programmable Fiber Polishing Machine using heat treatment all materials, and long service life
09. Polishing process by microcomputer control, may realize the polishing time and process more be precise.
10. Double insurance TN-S grounding system and leakage protection switch, to an extreme protect operator
11. Unique compensation setting function, it not only strictly control polishing film costs least, but also maintain high quality consistency.
Parameters:
Pressure way | 4 coil spring | Insert Loss | 0.3 dB (SM) |
Polishing capacity(max) | SC, FC, ST: 20, 48，72units LC: 24, 48，72units | Return Loss | 50 dB (PC) |
Polishing connector type | FC, SC, ST, LC, MU, MTP, MPO, MTRJ and so on | Radius | 10~25mm |
Motor speed | 0-150rpm rotation,3rpmre volution | Offset | 50 μ M |
Dimension | 230L*230W*350Hmm | Under cut | 50nm |
Film size | 5' ' | Repeatability | 0.1dB |
Weight | 24KG | Interchangeability | 0.2 dB |
Input voltage | 100-120VAC, 50/60Hz or 220-240VAC, 50/60Hz | Working Situation Temperature | -10— +40º C |
Polishing cycle | 1.4-2.4mins | Heavy punch | 500g or 250g |
Polishing chassis diameter | 130mm | Precession Speed | 3rpm |
Polishing time setting | 0-5min | Pressure Range | 0~5kg |
Counterweight pressure | 2.1~3.6kgf/cm | Fan | φ90mm |
Time Range | 0-300S | 3-4 min. (standard connectors) |
