SCPC 0.9mm Fiber Pigtail With Blue Cable

Model No.: SC 0.9mm
Products Category : Fiber Optic Pigtail & Loopback > SC Fiber Pigtail

Details

SCPC 0.9mm Fiber Pigtail With Blue Cable

Features:

1.Low insertion loss and back reflection loss fiber optic patch cord

2.Optical fiber patch cord with good echangeability

3.Connectors with good durability

4.High temperature stability fiber optic patch cord.

5.Standard: Telcordia GR-326-CORE

Specification:

Mode	SM		MM
Polish	UPC	APC	PC
Insertion Loss	Typical ≤0.2dB Maximum ≤0.3dB		≤0.25dB
Return Loss	≥50dB	≥65dB	≥35dB
Interchangeability	≤0.2dB
Repeatability	≤0.1dB
Durability	≤0.2dB (1000 times mating)
Tensile Strengh	> 10kg
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours)
