SC/PC fiber adapter of HK-7S IL&RL tester
Description
Fiber optic adapters are used in connecting fiber optic connectors.
It’s called Hybrid fiber optic adapter when the opposite connectors are different.
Features
Low insertion loss, high return loss
Good compatibility
High reliability & stability
Compact design
Comply with YD/T 127.2.3-2005 specifications
High precision of mechanical dimensions
Nickel plated brass body
Ceramic or Bronze Sleeve
Applications
Local Area Networks
CATV System
Telecommunication Network
Equipment Test
Technical Parameter
Parameter | Unit | LC, SC, FC, MU, ST, SC-ST, FC-ST, FC-SC, FC-LC, FC-MU | MTRJ | E2000 | ||||||
SM | MM | SM | MM | SM | ||||||
PC | UPC | APC | PC | PC | UPC | PC | PC | APC | ||
Insertion Loss (Typical) | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 |
Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥30 | ≥45 | ≥50 | ≥35 | ≥55 | ≥75 |
Exchangeability | dB | ≤0.2 | ≤0.2 | ≤0.2 | ||||||
Repeatability | dB | ≤0.2 | ≤0.2 | ≤0.2 | ||||||
Durability | Time | >1000 | >1000 | >1000 | ||||||
Operating Temperature | °C | -40~75 | -40~75 | -40~75 | ||||||
Storage Temperature | °C | -45~85 | -45~85 | -45~85 | ||||||
Plug and Unplug force (g/f) | 200—600 | |||||||||
Spec | Simplex and Duplex | |||||||||
