RY-3200 Power meter

Details

RuiYan RY-3200 Power Meter


Portable optical power meter is an accurate and durable handheld meter designed for the installation, operation and maintenance of optical fibre network. It is a compact device with backlight switch and auto power on-off ability. Besides, it provides ultra-wide measurement range, high accuracy, user self-calibration function and universal port. In addition, it displays linear indicators (mW) and non-linear indicators (dBm) in one screen at the same time.



Features



Self calibration by user himself

Rechargeable lithium battery supports continuous work for up to 48 hours.

Linear indicators (mW) and non-linear indicators (dBm) display in one screen

Unique FC/SC/ST universal port (see Figures 1, 2), no complex conversion

Optional auto power-off ability

Backlight ON/OFF



Specifications



Model

A

B

Calibration Wavelength(nm)

800~1700

Detector type

InGaAs

Measurement Range(dBm)

-70+10

-50+26

Uncertainty (dB)

+0.2(5%)

linearity (dB)

0.01

Display resolution(dB)

0.03

Frequency ID Hz

270 330 1K 2K

Wave ID nm

850,980,1300,1310,1490,1550,1625

Date Storage Capacity

1000

Communication Port

USB

Connector

FC/SC/ST Interchangeable

Alkaline battery

3AAA 1.5V orLi battery (9V)

Power Adapter(V)

8.4

Battery Operating time (h)

240 without backlight

Operation Temperature(oC)

-10(oC) +60

Storage Temperature(oC)

-25(oC)+70

Dimension(mm)

172*82*33

Weight(g)

310
