New product Japan Fujikura CT50 fiber cleaver
Compared to other existing cutting knives, the CT50 has a higher drop impact resistance and allows the staff to replace the blade, significantly reducing processing time and maintenance costs for the customer. The CT50 can automatically change the position of the cutting blade according to the cutting state of the fiber on the fusion splicer via Bluetooth. In addition, CT50 can complete fiber cutting and fiber waste collection in one step.
Product features
Can cut to 12 cores
Automatically rotate the blade position via a wireless connection
Users can replace blades and fiber platens by themselves
Cutting life reaches 60,000 times (16 positions and three heights)
The platen opens at a larger angle and makes it easier to access the fiber
Complete cutting and collect waste fiber in one step
Can cut to 12 cores
Automatically rotate the blade position via a wireless connection
Users can replace blades and fiber platens by themselves
Cutting life reaches 60,000 times (16 positions and three heights)
The platen opens at a larger angle and makes it easier to access the fiber
Complete cutting and collect waste fiber in one step
Product Description
PARAMETER | VALUE |
Applicable Fiber | Conventional silica optical fiber |
Fiber Count | Single and up to 12 fiber ribbon |
Coating Diameter | 250 μm to 900 μm |
Cladding Diameter | 125 µm |
Cleave Length | 5-20 mm with AD-50 adapter plate and 10 mm when using fiber holders |
Cleave Angle Capability | Typically <0.5 |
Blade Lifetime | 60,000 fiber cleaves (5,000 12-fiber cleaves) |
Dimensions (W x D x H) | 120 mm x 95 mm x 58 mm |
Weight | 300 g (0.66 lbs) |
