Module Fiber Microscope HK-400D

The integrated optical module end face detector mainly detects the female module, such as the end face inspection of all male and female optical devices such as SFP and qsfp modules. It is suitable for quality inspection of optical module and finished device manufacturers.

High definition of display

Ultra clear optical objective lens, high-definition image sensor and high-resolution liquid crystal display are used to show all kinds of dirt and scratches on the end face.

Easy to operate

Easy to adjust focusing system, easy to use, can quickly find the image, also easy to replace all kinds of test interface.

Reasonable appearance design

All metal spray paint shell is adopted to prevent electromagnetic interference and various vibration. The integrated fuselage design saves space and is convenient to use.

Stable focusing system

The industrial design concept makes the test image more stable and does not shake. The XY axis design makes it easy to adjust the image to the middle. It can also test multi-core products. The built-in industrial bearing can be used for a long time without jamming.

Display image storage function

The test image can be saved to analyze the image quality and improve the quality. (Note: the factory terminal detector does not include the photo taking function by default. Please inform us in advance if you need any function.)
