Mini-SC Waterproof Fiber Optic Connector

Details

Mini-SC Waterproof Fiber Optic Connector

The waterproof connector offers high performance armor fiber cable assemblies that are designed for use in different harsh environments and offer better protection than standard patch cords.

Stainless steel tube prevents fiber damage, improves system stability and reduces maintenance costs. They are suitable for LAN systems, FTTH, intelligent fiber optic networks in buildings, underground networks, closed-circuit television systems, broadcast and cable

networks.The waterproof connector has a variety of styles, such as waterproof cable connector, outdoor waterproof connector, plastic waterproof connector, 12-core and 24-core waterproof connector.


Specifications:




InsertionLoss(IL)                  (IEC 61300-3-4)MMSM Super PCSM Ultra PCSM Angle PCSM Angle PC Premiun
0.15dB type0.15dB type0.15dB type0.15dB type0.1dB max
ReturnLoss(RL)                    (IEC 61300-3-4)>30dB>45dB>50dB>60dB*
Operating temperature﹣40℃ to ﹢50℃
Durabilitymin 1000 cycles
Assemblityglue and polish
Connectionphysical contact
Lock   mechanismcoupling nut and snap-on
StandardsTelcordla GR-3120
Ferrule   materialfull ceramic zirconia
