LC-SC DX SM Flat Cable Standard Patch Cord The Standard Patch Cord is used for detection and calibration. Specifications & Performances:
your interconnection needs. They are available in any length . The patch cord are factory terminated, assembled, tested and inspected prior to shipment.
All patch cords are manufactured using OFNR riser grade cable, LSZH, plenum, and premium customized specs available upon request, and 100%
factory tested to ensure the performance to meet TIA/EIA-568-8-2, iso11801:2002 and EN 50173-1 standards. All assemblies are tested to meet Telcordia
GR326-CORE.
Applications: l Telecommunication
l CATV l LAN & WAN l Network l Broadband l FTTx
Homk is your reliable supplier of SPP-LC-LC-P(U)-SM-XX-X Sopto Patch Cords LC to LC connectors PC/UPC Simplex MM 0.9/2.0/3.0mm customized lengths.
We test each piece of SPP-LC-LC-P(U)-SM-XX-X Sopto Patch Cords LC to LC connectors PC/UPC Simplex MM 0.9/2.0/3.0mm customized lengths optical
transceiver before shipment to make sure the patch cords can work in your system without any problems.
Features:
l Meet IEC, JIS, Bellcore international standard requirements
l Stable and high quality
l High performance and cost effective l Mass and flexible production meeting various demand
l Custom assemblies available upon request
l OEM available upon request
| Type | SM |
| Polishing | UPC |
| Insertion loss | A1.I.L:0.07dB B1.I.L:0.08dB |
| B1.I.L:0.09dB B2.I.L:0.02dB | |
| Return loss | RL:55.9dB RL:57dB |
| RL:59.7dB RL:57.7dB | |
| Durability(500 matings) | ≤0.2dB increase(Max) |
| Operating Temperature | -20°C-+75°C |
