Korea INNO IFS-15S Fusion Splicer

Details

Weight	1.82kg without battery
Applicable Fibers	SM(ITU-TG.652)/MM(ITU-TG.651)/DS(ITU-TG.653)/NZDS(ITU-TG.655)/ITU-TG.657A/ITU-TG.657B
Compatible Fiber/Cable	0.25mm/0.9mm/2.0mm/2.4mm/3.0mm/ Flat cable
Fiber Count	Single Core
Fiber Holder	Universal type fixed holder
Fiber Diameter	Cladding:80-150μm/Coating:100-1000μm
Fiber Cleave Length	Diameter 250μm-1000μm: cleave length 8-16mm
Splice Mode	Max/Preset 64/24
Typical Splice Loss	SM:0.02dB/MM:0.01dB/DS:0.04dB/NZDS:0.04dB/G.657:0.02dB (ITU-T Standard)
Return Loss	>>60dB
Splicing Time	SM Quick Mode:7second
Estimated Splice Loss	Yes
Attenuation Splicing	0.1dB-20dB (0.1dB step)
Heat Oven/Heating Time	Heat Mode: 32/Heating Time (Typical): 35 second
Applicable Protection Sleeve Length	10mm, 20mm, 30mm, 40mm, 50mm, 60mm
Results Storage	100 user mode
Mechanical Proof Test	1.96~2.25N [Based on the fiber count]
Operating Condition	Operating Altitude:0-5000meter above sea level, 95% relative humidity, - 10~50°C, Max Wind 15m/s
Storage Condition	0~95% relative humidity, -40~80°C, Battery: -20~ 30 °C
Size/ Color	155130137(LWH)/Rose Red
Display	2 Cameras and 4.3 inch color LCD monitor (with high resolution and shock-proof protect surface)
Fiber View & Magnification	X/Y 300X, 180X
Power	DC 18V Power Supply
No of splice/Heating with Battery	Typical 157 times(Splice + Heat) / Splice + Heat=26.7mA/time Battery:4200mAh
Electrode	2500 Times Splicing
Terminal	USB 2.0/RS232 (for storage and upgrading)
Other Functions	IFS-15S Exclusive Software /Standard Heat Oven
