JW3109 Optic Light Source
JW3109 optical light source can provide 1 to 4 output wavelengths to meet specific requirements,
including the 650nm red source and the 1310/1550nm wavelengths for single mode fiber or the 850/1300nm
wavelengths for multimode fiber, as well as other wavelengths according to customer needs.
Together with the JW3208 optical power meter, it is a perfect solution for the fiber optic network characterization.
Feature:
1.Provides 1~4 output wavelengths which can be optional according to customer’s needs
2.CW, 2Hz modulation output at 650nm, and CW, 270Hz,1KHz,2KHz
3.modulation output at other wavelengths.
4.High stability of the output power
5.Stable output wavelength
6.Backlight LCD display supports night operation
7.Compact size and decent appearance
8.Large LCD, easy operation
Application
Maintenance in Telecom
Maintenance CATV
Test Lab of optical fibers
Other Fiber Optic Measurements
Specification:
Type | JW3109 |
wavelengths(nm) | 1310 /1550 850/1300 |
emitter Type | FP-LD |
Ouput Power(dBm) | -7~-6 |
spectral Width(nm) | ≤10 |
0utput Stability | ±0.05dB/15mins; ±0.1dB/ 8hours |
modulation Frequencies | CW.2Hz,270Hz,1KHz,2KHz |
optical Connector | FC/PC |
power Supply | Rechargeable battery +power supply adaptor |
battery Operating Time(hour) | 40 |
operating Temperature | -10~+60 |
storage Temperature | -25~+70 |
dimension(mm) | 210*115*55 |
weight(g) | 515 |
