INNO VF-78 fiber cleaver

Details

INNO VF-78 fiber cleaver


VF-78 High Precision Cleaver is an instrument for high precision fiber cutting. It is compact and light, making it ideal for both single and 250μm adaptable ribbon fiber cleaving (2-12 core). The blade provides over 48,000 cleaves by easy and simple blade position selection. Additionally, it has an automatic collector for fiber shards and off cuts.


Features
  • Easy-step operation to complete the cleaving and collection of waste fiber shards automatically.

  • Convenient and quick to operate. Either hand-held or on table/worktop surfaces

  • Very easy fiber setting and placing and, no need for blade height adjustment, therefore improving work efficiency and low maintenance cost.

  • Smart design of pressure pads preventing the fiber from damage by the return of the blade carriage

  • Made for magnesium alloy materials, giving high strength and stability. Small, compact size and light weight.

Specifications:

Applicable fibers

optical fiber

Bare fiber diameter

125um

Cleaving angle

0.5 degrees with single fiber

Blade life

48,000 fibers (1,000 fibers x 3 height x 16 positions)

Blade positions

3 height and 16 rotating positions

Dimensions

102W x 82D x 46H (mm)

Weight

350g
