AOP 100T MINI Fiber Optical Power Meter
Specifications
1.Test the loss of the fiber
2.850/1300/1310/1490/1550/1625nm
3.Reference value set
4. One year warranty
Application
Power measurement
Test the loss of the fiber
Feature
850/1300/1310/1490/1550/1625nm
Reference value set
One year guarantee
Wide measuremen range: Max. 78dB;
High resolution: 0.01dB;
Good accuracy:±0.2dB;
Insertion loss test in dB;
SM or MM applications;
FC/PC and 2.5mm universal connector;
850/1300/1310/1490/1550/1625nm calibrated wavelengths;
Data storage
Data transfer(optional)
7X24 r eal-time test on PC; (optional)
Built in VFL (optional) ;
Energy save mode ;
Reference value storage;
Full energy can support above 100hours operation;
Model Options:
AOP100X-Y-U
X: RANGE OF OPM | Y: POWER OF VFL | U | |||
+10~ -70dBm | +18~ -60dBm | +26~ -50dBm | 1mW | 10mW | data transfer and real time monitor |
T | M | C | V01 | V10 | with software on PC |
