HK-510 mini power meter

Details

HK-510 mini power meter


Features

High sensitivity, large dynamic range

Common interface design: FC/SC/ST interface, the standard FC, SC, adapter interface

Miniature casing protection design, compact and easy, falling to prevent accidental damage to the instrument detector.

Fast response without preheating

Low voltage display function

Optional automatic shutdown function

Optional automatic shutdown backlight function

New users since the calibration function Logarithmic power (dBm) and linear power (xW) measurement

Big screen and LED backlit display



Specifications



Measurement Range(dBm)
-70~+10-50~+26
Calibration Wavelength(nm)800~1700
Detector typeInGaAs
Uncertainty (dB)<&plusmn;3%(-10dBm,22℃)
Display resolution(dB)0.1% / 0.01dBm
Operation Temperature(oC)-10~+50
Storage Temperature(oC)-20~+70
Working Humidity90%(+30),RH
ConnectorFC,SC(ST LC optional)
Alkaline battery3AAA 1.5V orLi battery (9V)
Battery Operating time (h)120h
Weight(g)160
Dimension(mm)130&times;63&times;29
