HK-400R Polishing Disc(MT APC/PC & MPO APC/PC)

Details

HK-400R Fiber Microscope Fiber Adapter (MT APC/PC & MPO APC/PC)


This MPO Fiber Adapter use for HK-400R Fiber Microscope.

The fiber microscope is the table model used in inspecting the fiber optic connector end surface quality. It has high definition of inspection and is convenient and fast operation, precise and highly effective. The image is clear and bright. It saves the time, reduces the cost. It has strong function of applications. It is your end of the optical fiber connectors detection of measuring tool. Ideal through the monitor display optical fiber connectors end of the image, and other fiber microscope, compared with common observation, can be in uniform inspection standard, which is beneficial to the related training and Technical personnel.

Principle:
Put the fiber connector into fiber microscope adapter, LED light will directly Irradiate fiber and ceramic ends, through the optical amplifier, the working life is long, the internal LED illumination light bulb life for 100000 hours, the interior does not have the user to be possible to service the part. Security laser, in sets at the CCD camera(not human eye) watches the optical fiber end surface, even if inspects is transmitting the laser optical fiber end surface, also does not have the security problem transfer Images to CCD, CCD image amplifier, video signals, and turn to transmission to the corresponding monitors, on the monitors can get, CCD camera, including monitoring device.

The fiber microscope suits the scope to be broad, basically may inspect any fiber optic connector. And it can offer pre-centralized positioning, the core image always demonstrates in the central position. It is human body engineering design, suits specially in the fiber optic connector manufacturer.
