HFOC Fiber Optic Connector
Description:
OPTOKON manufacturers the hardened HFOC connector,compatible with OptiTap connector for
use in the drop cable portion of a preconnectorized,advantage solution network.The connector is
designed to be installed on einforced "Push cable",which is designed for FTTH projects.Preconnectorized
push cables,as part od duct system,significantly reduce push cable installation time,thus saving money
and accelerating subscriber connectors.
Features/Benefits:
1)Proven design provide a hardened connector for outside plant deployment
-Single fiber,singlemod SC/APC hardened connector
-Connector is designed to install on Push Cable
-Environmentally-sealed connector housing permits rapid connection to external flush-mounted bulkhead adapter
2)Robust design keeps connector intact during installation
-Can be pulled through 1.25-in conduit
-Integral pulling eye/connector cap designed for 100 ibf maximum pullling tension
3)Fully standards-compliant product ensure the highest network reliablitity and durability
-Connectors designed and third-party tested to Telcordia GR-3120 requirements
Specifications: | |||||
InsertionLoss(IL) (IEC 61300-3-4) | MM | SM Super PC | SM Ultra PC | SM Angle PC | SM Angle PC Premiun |
0.15dB type | 0.15dB type | 0.15dB type | 0.15dB type | 0.1dB max | |
ReturnLoss(RL) (IEC 61300-3-4) | >30dB | >45dB | >50dB | >60dB* | |
Operating temperature | ﹣40℃ to ﹢50℃ | ||||
Durability | min 1000 cycles | ||||
Assemblity | glue and polish | ||||
Connection | physical contact | ||||
Lock mechanism | coupling nut and snap-on | ||||
Standards | Telcordla GR-3120 | ||||
Ferrule material | full ceramic zirconia |
