Fiber Optical OptiTap MINI-LC Fiber Connector
Specifications
New design FIBERCAN Toptap SC FTTA outdoor patch cord assemblies provide an cost effective, easy, environmental seal and mechanical protection for 1 fibers simplex SC style connections. Inside cover can protect ferrule end face far away scratch when mating with receptacle; Special fool-proofing design equal to HUAWEI Mini SC connector has blind-mating function; One hand Bayonet-style mechanical latch. The assemblies guarantee an easy, one-step connection system with the combined push-pull insertion and bayonet-style mechanical latch. It provides quick installation solutions and has good performance on mating receptacle / Adapter. Cable can be armoured or non-amoured. The industrial panel-mount, plastic adapters serve as a sealed feed-through for the fiber connection. The new industrial integrated flange-mount adapters are designed for tight, side-by-side applications.
Features :
1. Cost effective solution for in house termination
2. IP67 Water immersion and Dust protection for hash environment.
3. Chemical Resistance.
4. Simple assembly requiring no special tools ·
5. Push-pull insertion with bayonet-style mechanical latch provides easy installation and removal
6. Durable mechanical mating, minimum of 500 matings.
7. Wide range of operational temperature for outside plant -40 to+85°C
8. SC/APC IL<0.3 typically.
9.100% optically tested to ensure quality performance assemblies.
Application :
1; Telecom networks 5G tower;
2; CATV, LAN&WAN.
3; Broadband;
4; CPRI, FTTP, FTTA
Specifications: | |||||
InsertionLoss(IL) (IEC 61300-3-4) | MM | SM Super PC | SM Ultra PC | SM Angle PC | SM Angle PC Premiun |
0.15dB type | 0.15dB type | 0.15dB type | 0.15dB type | 0.1dB max | |
ReturnLoss(RL) (IEC 61300-3-4) | >30dB | >45dB | >50dB | >60dB* | |
Operating temperature | ﹣40℃ to ﹢50℃ | ||||
Durability | min 1000 cycles | ||||
Assemblity | glue and polish | ||||
Connection | physical contact | ||||
Lock mechanism | coupling nut and snap-on | ||||
Standards | Telcordla GR-3120 | ||||
Ferrule material | full ceramic zirconia |
