FTTX Waterproof Metal ODC Fiber Connector

Details

FTTX Waterproof Metal ODC Fiber Connector

Overview:



With the continuous development of optical fiber communication technology, 3G commercial trial network, high-speed local area networks and optical access network such as the market that is a sustained manner. Especially in the 3G, 4G, and WiMax base stations and fiber-optic distributed zoom technology, ODC fiber optic cable connector assemblies are rapidly becoming the standard connector interface.



ODC fiber optic connectors for the new generation wireless base stations pulled far (WCDMA/TD-SCDMA/WiMax/GSM) tailored products that can be meet the FTTA(fiber to the top of the tower) program requirements for outdoor environment conditions and adverse weather conditions.



Feaures:

  • Robust connection, IP65 protection, salt-mist proof

  • Easy, reliable and cost-effective installation

  • Resistant in harsh environment, adapted for outdoor useFast and easy connection: blind mate coupling

  • Price-Competitive

  • Low Insertion Loss & PDL

  • Factory-terminated and Tested


Pecification

Fiber Core2,4,6,8 etc
ModeSinglemodeMultimode
Operating Wavelength(nm)1310/1550850/1310
PolishmentUPCAPCUPC
Insertion Loss(Max.dB)0.70.6
Return Loss(Min.dB)556035
Mating times500 Min
Durability(Max.dB)0.2
Reaptability(Max.dB)0.5
Operating Temperature(℃)-40~+85
Storage Temperature(℃)-40~+85
