EXFO EPM-50 power meter

Details

EXFO EPM-50 power meter


Features:

  • Rugged design

  • Interchangeable connector adapters

  • 300 hours of battery life

  • Tone recognition for fi ber identification

  • Universal push-pull interface

  • Reference function for direct loss measurements



MODELEPM-53EPM-53X
Power meter port InGaAsInGaAsX
Power range (dBm) 10 to –60 26 to –50
Number of calibrated wavelengths55
Power uncertainty ±5 %±5 %
Resolution (dB)0.010.01
Display unitsdB/dBm/WdB/dBm/W
Tone detection (Hz)270, 1 k, 2 k270, 1 k, 2 k
Battery life (hours)>300>300
Warranty (year) 1 1
Size (H x W x D)189 mm x 78 mm x 37 mm
Weight 0.4 kg (0.9 lb)
Temperature operating—10 °C to 50 °C (14 °F to 122 °F)
Storage—40 °C to 70 °C (–40 °F to 158 °F)
Relative humidity 0 % to 95 % non-condensing
