China JW3223 multimeter

Details

China JW3223 multimeter


Features

  • Great LED display,easy to operate

  • Automatic switching function of the internal source wavelength

  • Detection of the frequency light

  • Power measurement in dBm and mw

  • Wide-range detection zone

  • Battery indication

Applications:

Maintenance of telecommunication project

  • CATV project maintenance

  • Digital data network project maintenance

  • Teaching and research in optical communications

  • Other fiber-optic projects

Technical Specifications



Model

JW3223

Operating wavelength(Power Meter Module)

1310, 1490, 1550, 850, 1300, 1625

Detector Type

InGaAs

Out put power(VFL module)

1mW

Power Measurement Range

-70~+3dBm

Uncertainty

±0.5dB

Resolution

0.01

Operation temperature

-10~+60 °C

Storage Temperature

-25~+70°C

Auto-off function

Yes, Auto-off after 10minutes idle time

Battery Life @ OPM

180 hours

Battery Life @ VFL

60 hours

Power Supply

3pcs AA Batteries

Weight

700g (including batteries)

Size

192*102*50
