Cat7 10Gbps 600MHz SSTP Network Cable Descriptions Of Lan cable Product Description: Rated temperature: 60℃,75℃,90℃ Installation temperature: -30℃~+50℃ Minimum bending radius: 8D Reference Standard: UL444,UL1581 Solid bare copper conductor Pair shield with Alu foil PVC/ LSZH jacket,RoHS/REACH Compliant Comply to TIA/EIA-568-C.2-10,IEC61156-5,EN50173&ISO/IEC 11801 Feature&Advantages: CAT6A Cable is designed for improve crosstalk performance between cables applying in 1000Base-T Ethernet with up to 500MHz bandwidth,Skin-foam-skin insulation and pair shield design make the cable with excellent shielding&anti-EMI performance.This cable complies to all the requirements for CAT6A of TIA/EIA568B-10&IEC61156. Cable Construction (CAT6A) Item No. Construction Nominal Conductor Dimension (mm) Nominal Insulation Diameter (mm) No.of Paris Nominal Cable OD. (mm) Type of Jacket 216101 FFTP 0.570 1.35 4 7.6 PVC 216601 FFTP 0.570 1.35 4 7.6 LSZH
