Automatic Fiber Optics Curing Oven (HK-310)

Specifications

Automatic Fiber Connector Curing Oven, auto alarm and pneumatic push out mechanism prevents over heating.

Main Features:
Fully automated operation, timer controlled. Once the tempeture and heating time are set the heating tray will be ejected when time is up to avoid overheating.
Timer controlled alarm, to notify the operator when the heating time is up.
Total of 30 connectors can be placed for heating at the same time.
Modular heating trays that hold all types of connectors, one oven fits all.
Two horizontal heating trays are for heating ferrules of 2.5mm and / or 1.25mm.
The vertical heating block is for SM coonectors.
Ferrule heating plates can be supplied subject to demand of specific outer jacket and
varied type of connectors.
Individual heating timing control, the alarm will remind operator when heating is done,
the auto pusher will secure heating quality.

Specifications:
Machine size 320W x 370L x 220H mm
Net weight 12 KG
Power AC 110/220V , 50/60 Hz , 600W
Consumption air 5 kgf / cm square
Heating temperature 399 C (Max.)
Time setting 99 Min. 59 Sec. (Max.)
Connetor heat block 30 Position , Connector Style Available.
Ferrule heat block 2 SETS.
