AI-8 Fiber Fusion Splicer

Details

NEW Ftth Fiber Cable Fusion Splicer Factory Price Optical Fusion Splicer AI-8


Specifics:

l   Stable performance of dual observation, tune core type fusion machine.

l   Typical fusion time:7 seconds

l   Typical heating time: 30 seconds

l   Shockproof, dustproof, rainproof

l   Display magnification: 250 times

l   Large capacity lithium battery, charging times of up to 300-500 cycles

l   Bright low-power LED lights, 5.6 inches LCD screen

l    Interface is simple, with humane, intelligent menu design

l   USB port for easy data download and software updates

l   Recessed wind cover, can perform fusion at 15M / S strong winds

High-accuracy V-groove, high precision, good abrasion resistance

Signal  Fire AI-8 adopts the latest core alignment technology with auto focus  and six motors, it is a new generation of fiber fusion splicer. It is  fully qualified with 100 km trunk construction, FTTH project, security  monitoring and other fiber cable splicing projects. The machine uses  industrial quad-core CPU, fast response, is currently one of the fastest  fiber splicing machine in the market; with 5-inch 800X480  high-resolution screen, the operation is simple and intuitively; and up  to 300 times focus magnifications, making it is very easy to observe the  fiber with naked eyes. 6 seconds speed core alignment splicing, 15  seconds heating, the working efficiency increased by 50% compared to  ordinary splicing machines.
Under  the conditions of rigorous testing, the performance is still  outstanding; toolbox is small, exquisite, durable, and with unique bench  design. The design of operating platform reflects the humanistic care;  unique lighting design, it is convenient for night construction or  repair. Screen brightness is adjustable and it is convenient for outdoor  sunshine environment operation. The core parts are using imported  brands, aviation metal body material with exquisite details. With the  combination of advanced technology and design, the new generation of  optical fiber fusion splicer will bring you a reliable and comfortable  user experience.

Applications:

  • FTTx,  FTTH, FTTB, FTTO, Telecom network, CATV.Provide fusion and storage  appliance for optical cables,for indoor fiber optic cable distribution.





Specifications :



Applicable Fibers

SM, MM, NZ-DS, EDF , Pigtail, Rubber-insulated series wire

 Series

Average Splice Loss

0.025dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF)

Return Loss

≥60dB

Tension Test

2.0N (200gf) (standard)



Typical splicing time

6seconds

Typical heating time

15 seconds

Protection Sleeve Length

40mm, 60mm

Operating Language

Chinese, English

Operating Conditions

-15~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude)

Power Supply

 7800mAH large capacity battery

Monitor

5 inches 800x480 high-resolution screen

Fiber image magnification

Simultaneous X and Y views with 300 times magnification

Optical Fiber Fixture

Bare Fiber & Rubber-insulated Wire

Dimensions

122(W)*130 (D)*148(H) (mm)

Net Weight

2.6kg
