Details
ADSS /OPGW Electric Optical Cable Suspension Clamp
Breaking Strength:20KN
Recommended Span Length: ≤100m
Data Sheet:
Specification Model | Suitable Cable | Length (mm) | Rubber Model |
| AXJ 1110 020 | 9.0-11.1 | 116 | TD 1110 |
| AXJ 1330 020 | 11.2-13.3 | 116 | TD 1330 |
| AXJ 1550 020 | 13.4-15.5 | 116 | TD 1550 |
| AXJ 1770 020 | 15.6-17.7 | 116 | TD 1770 |
One set of Tangential Suspension Clamp includes Housing, Rubber Insert and a Shackle U-4.
